OD-580T Mini Skid Steer Loader

The OD-580T is the diesel tracked version of the Mini Skid Steer Loader. It is reliable, safe and to built to deliver maximum performance for Australia’s most demanding environments. Designed by Australians, for Australians, OzDiggers Mini Skid Steer Loaders are for those who like to get it done, and get it done right.

Our diesel model is available in tracked and wheel configurations with a powerful Kubota diesel engine or as a petrol wheeled configuration, powered by a Briggs & Stratton Vanguard petrol engine.

Showcasing the OD-580-T Digger

Watch as the OD-580-T (Tracked Diesel model) is put through its paces by Jamie Gray of Landscape Contractor Magazine. With our 230mm tracks, single joystick, dual hydraulics and spring loaded standing platform it’s easy and comfortable to operate. Watch and see its capabilities and hear about what sets it apart.

Need Finance?

Ozdiggers has partnered with DBS Finance to offer finance on all our equipment. Ease your cash flow with affordable payments, click to view examples and for an obligation-free quote.

Learn More

Specifications

OD-580T Tracked Diesel Model

Dimensions

Operating height: 2695mm
Height to bucket hinge pin: 2000mm
Height to top: 1585mm
Overall length with GP bucket: 2694mm
Overall length without bucket: 2220mm
Wheelbase: 1085mm
Overall width: 1067mm
Mini ground clearance: 94mm
Angle of departure: 27°
Rated loading capacity (35%): 454kgs
Track Width: 198mm

Power

Engine maker: Kubota engine
Fuel type: Diesel
Rating power: 25HP
Max. speed: 7.95km/h

Battery

Electrical Voltage: 12V
Battery Type: 45AH made by YUASA

Hydraulic System

Working system pressure: 180 bar
Working system Flow rate: 55 L/min
Driving System pressure: 250bar
Driving system Flow rate: 119.7 L/min
Auxiliary Hydraulic flow rate: 48 L/min

Fluid Capacities

Fuel tank capacity: 35 L
Engine oil: 4.5 L
Hydraulic reservoir capacity: 35 L

Features

Compatible with OzDiggers Modular Attachment System
US Donaldson 3-stage air filter US PERMCO triple pump and WHITE motor, Italian HC control valve
Japan NSK bearing, 60H strong chains
Big aluminium radiator, LED lights
400kg load capacity
Modular System – Compatible with OzDigger or third party attachments.
Designed by Australians for Australians
